BSIDE ESR02 Pro Digital Transistor Tester Chip Component Meter

Description This meter is a small tool for the engineer electronic maintenance and factory. It is very easy to test plug-in and SMD devices also can test different kinds of diodes triodes thyristors MOSFET enable to analysis the device type the polarity of the pin the output HFE the valve voltage the junction capacitance of the FET.Note Before testing the capacitor be sure to discharge it otherwise it may damage the internal circuitIf using DC supply please choose DC 9V - 12V adapter including 9V and 12VCan be powered by a 9V 6LR61 battery not included when the battery power is under 6V please replace a new oneParameters Resistor 0 - 50 ohm resolution 0.01 ohmCapacity 25pF - 100mF resolution 1pFInductor ESR measuring resolution 0.01 ohmUsing InstructionPush "POWER TEST" to power on and start a test multiple measurements can be repeated by this key auto power off 20 seconds after measurementProvide three kinds of socket each socket pin 1 pin 2 and pin 3 are connectedThere is a table "typical ESR value of electrolytic capacitor" at the back it is for guiding only these are typical value for standard grade electrolytic capacitor at room temperatureCalibrationShort the test pin 1 2 3 together and push "POWER TEST" button then the screen prompts to enter calibration push the button again within 2 seconds to confirm. Few seconds latter the screen prompts to release pin 1 2 3 release them and wait for calibration finish 0.219 Package weight 0.254 kg Package SizeL x W x H 17.50 x 10.00 x 6.00 cm 6.89 x 3.94 x 2.36 inches Package Contents 1 x Digital Transistor Tester 1 x User Manual in English and Chinese
